Waveshare OV5640 FF 5MP USB Camera Module, Support 1080P Video Recording
Waveshare OV5640 FF 5MP USB Camera Module, Support 1080P Video Recording
Available to order
Processing time: 1-3 days
Couldn't load pickup availability
Estimated delivery: 6-13 working days
Ships from South Africa • No import duties
Ships from China (Standard) • Import tax and duties included
Ships from China (Standard) • Import tax and duties excluded
Ships from Hong Kong (Direct) • Import tax and duties excluded
Description
The Waveshare OV5640 FF 5MP USB Camera Module is a camera module designed for video recording and image capture. It is suitable for everyday use in various electronic projects requiring high-resolution imaging.
- Product Type: Camera Module
- Compatibility: OV5640
- Material: Not specified
- Key Feature: 5MP resolution
- Pixels: 5MP
- Sensor: OV5640
- Interface: USB 2.0
- Camera Sensor Size: 1/4 inch
- Aperture (F): 2.8
- Focal Length (EFL): 3.29 mm
- Field of View (FOV): 68 degrees
- Distortion: Less than 1%
- Focusing: Fixed-Focus
- Image Format Support: MJPG, YUV422
- Static Image Resolution: 2592 x 1944
- Video Recording: 15 FPS at 2592 x 1944, 30 FPS at 1920 x 1080, 30 FPS at 1280 x 720
- Operating Voltage: 5V +/- 5%
- Camera Size: 8.5 x 8.5 mm
- Module Size: 9 x 62 mm
